English
10
Storage
Chipset:
•
1 x Ultra M.2 Socket (M2_1, Key M), supports type 2280
SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes*
•
4 x SATA3 6.0 Gb/s Connectors**
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
** If M2_1 is occupied by a SATA-type M.2 device, SATA3_0
will be disabled.
Connector
•
1 x eDP Signal Connector
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x Chassis Fan Connector (4-pin)
* e Chassis Fan Connector supports the chassis fan of maxi-
mum 1A (12W) fan power.
•
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports
ESD Protection)
•
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)
BIOS
Feature
•
AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V
PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage
Multi-adjustment
