3
English
H610M-IT X/eDP
•
Supports Triple Monitor
•
Supports eDP 1.4 with max. resolution up to Full HD
(1920x1080) @ 60Hz
•
Supports HDMI 2.1 TMDS Compatible with max. resolution
up to 4K x 2K (4096x2160) @ 60Hz
•
Supports DisplayPort 1.4 with DSC (compressed) max.
resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @
120Hz
•
Supports HDCP 2.3 with eDP 1.4, HDMI 2.1 TMDS
Compatible and DisplayPort 1.4 Ports
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
•
Supports Surge Protection
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
Giga PHY Intel® I219V
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports UEFI PXE
Wireless
LAN
•
802.11ac WiFi Module
•
Supports IEEE 802.11a/b/g/n/ac
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 433Mbps
•
Supports Bluetooth 5.1 + High speed class II
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
•
4 x USB 2.0 Ports (Supports ESD Protection)*
* CNVi BT shares bandwidth with the top USB 2.0 port (USB_1).
When CNVi BT is used, USB_1 becomes unavailable.
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
To Next Page
