No. Description
1 Chassis Fan Connector (CHA_FAN2)
2 ATX 12V Power Connector (ATX12V1)
3 CPU Fan Connector (CPU_FAN1)
4 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6 ATX Power Connector (ATXPWR1)
7 USB 2.0 Header (USB_5_6)
8 USB 3.2 Gen1 Header (USB32_3_4)
9 SATA3 Connector (SATA3_0)
10 SATA3 Connector (SATA3_1)
11 SATA3 Connector (SATA3_2)
12 SATA3 Connector (SATA3_3)
13 System Panel Header (PANEL1)
14 Clear CMOS Jumper (CLRMOS1)
15 Chassis Speaker Header (SPEAKER1)
16 Front Panel Audio Header (HD_AUDIO1)
17 eDP Signal Connector (EDP1)
