No. Description
1 CPU Fan Connector (CPU_FAN1)
2 ATX Power Connector (ATXPWR1)
3 System Panel Header (PANEL1)
4 Chassis Intrusion and Speaker Header (SPK_CI1)
5 Clear CMOS Jumper (CLRMOS1)
6 Chassis Fan Connector (CHA_FAN1)
7 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)
8 COM Port Header (COM2)
9 USB 2.0 Header (USB4_5)
10 USB 3.1 Gen1 Header (USB3_1_2)
11 USB 2.0 Header (USB2_3)
12 SATA3 Connector (SATA3_1)
13 SATA3 Connector (SATA3_2)
14 Front Panel Audio Header (HD_AUDIO1)
