ASROCK J4105B-ITX User Manual

2
English
1.2 Specications
Platform
•
Mini-ITX Form Factor
•
Solid Capacitor design
CPU
•
Intel® Quad-Core Processor J4105 (up to 2.5 GHz)
(for J4105B-ITX)
•
Intel® Dual-Core Processor J4005 (up to 2.7 GHz)
(for J4005B-ITX)
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 SO-DIMM Slots
* 2GB DRAM per module is not supported.
•
Supports DDR4 2400/2133 non-ECC, un-buered memory
•
Max. capacity of system memory: 8GB
Expansion
Slot
•
1 x PCI Express 2.0 x16 Slot (PCIE1: x2 mode)
Graphics
• Integrated Intel® UHD Graphics 600: 12 EUs inside (Up to
750MHz) (for J4105B-ITX)
• Integrated Intel® UHD Graphics 600: 12 EUs inside (Up to
700MHz) (for J4005B-ITX)
• DX12, OpenGL 4.3, OGL ES 3.0, OpenCL 2.0
• HW Acceleration Decode: HEVC (H.265) 8 bit, HEVC
(H.265)10 bit, H.264 @ Lvl5.2 (AVC), JPEG/MJPEG, VP8,
VP9 8bit, VP9 10 bit
• HW Acceleration Encode: HEVC (H.265) 8 bit, HEVC
(H.265)10 bit, H.264 @ Lvl5.2 (AVC), JPEG/MJPEG, VP8,
VP9 8bit
• Dual graphics output: support D-Sub and HDMI ports by
independent display controllers
• Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 30Hz
• Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
• Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate
Audio) with HDMI Port (Compliant HDMI monitor is
required)

ASROCK J4105B-ITX Specifications

General

Audio chip	Realtek ALC887
Certification	FCC, CE, ErP/EuP
Component for	PC
Motherboard chipset	-
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Cables included	SATA
Drivers included	Yes
Processor family	Intel® Celeron®
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 2.0 connectors	2
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Graphics card	UHD Graphics 600
OpenGL version	4.3
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	3.0
Memory channels	Dual-channel
Memory slots type	SO-DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	2133, 2400 MHz
Processor cores	4
Processor model	J4105
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
