N100DC-ITX
For the latest updates of M.2 SSD module support list, please visit our website for details:
http://www.asrock.com
20
o
Step 4
Align and gently insert the M.2 SSD
module into the M.2 slot. Please be
aware that the M.2 SSD module only
ts in one orientation.
NUT1NUT2
Step 5
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw
as this might damage the module.
