N100DC-ITX
No. Description
1 Chassis Fan Connector (CHA_FAN1)
2 Clear CMOS Jumper (CLRMOS1)
3 288-pin DDR4 DIMM Slot (DDR4_A1)
4 Chassis Fan Connector (CHA_FAN2)
5 Chassis Intrusion and Speaker Header (SPK_CI1)
6 System Panel Header (PANEL1)
7 USB 2.0 Header (USB_56)
8 USB 2.0 Header (USB_78)
9 Print Port Header (LPT1)
10 USB 3.2 Gen1 Header (USB3_34)
11 SATA Power Connector (SATA_PWR1)
12 SATA3 Connector (SATA3_0)
13 SATA3 Connector (SATA3_1)
14 Front Panel Audio Header (HD_AUDIO1)
15 SPI TPM Header (SPI_TPM_J1)
