ASROCK N68C-S User Manual

1111
1111
11
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
1 PS2_USB_PW1 Jumper 16 USB 2.0 Header (USB6_7, Blue)
2 CPU Fan Connector (CPU_FAN1) 17 USB 2.0 Header (USB4_5, Blue)
3 ATX 12V Power Connector (ATX12V1) 18 Chassis Speaker Header
4 CPU Heatsink Retention Module (SPEAKER 1, Purple)
5 AM2 940-Pin CPU Socket 19 System Panel Header (PANEL1, Orange)
6 2 x 240-pin DDR2 DIMM Slots 20 Chassis Fan Connector (CHA_FAN1)
(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Clear CMOS Jumper (CLRCMOS1)
7 2 x 240-pin DDR3 DIMM Slots 22 Print Port Header (LPT1, Purple)
(Dual Channel: DDR3_A1, DDR3_B1; Blue) 23 Floppy Connector (FLOPPY1)
8 ATX Power Connector (ATXPWR1) 24 Power Fan Connector (PWR_FAN1)
9 Primary IDE Connector (IDE1, Blue) 25 Internal Audio Connector: CD1 (Black)
10 Primary SATAII Connector (SATAII_1 (PORT 0.0)) 26 Front Panel Audio Header
11 Third SATAII Connector (SATAII_3 (PORT 1.0)) (HD_AUDIO1, Lime)
12 Fourth SATAII Connector (SATAII_4 (PORT 1.1)) 27 PCI Slots (PCI1- 2)
13 Secondary SATAII Connector 28 PCI Express x16 Slot (PCIE2)
(SATAII_2 (PORT 0.1)) 29 PCI Express x1 Slot (PCIE1)
14 SPI Flash Memory (8Mb) 30 NVIDIA GeForce 7025 / nForce 630a
15 USB 2.0 Header (USB8_9, Blue)
NVIDIA
GeForce
7025 /
nForce
630a
FSB800
DDRII_1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
IDE1
SATAII_1
SATAII_2 SATAII_4
(PORT 0.0)
(PORT 0.1) (PORT 1.1)
SATAII_3 (PORT 1.0)
CHA_FAN1
SPEAKER1
1
HDLED RESET
PLED PWRBTN
1
PANEL1
11
ATXPWR1
8Mb
BIOS
CMOS
BATTERY
1
CLRCMOS1
CPU_FAN1
ATX12V1
PS2_USB_PW1
1
20.8cm (8.2-in)
24.4cm (9.6-in)
1
USB4_5
SOCKET AM2
FSB800
DDRII_2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
1
USB6_7
1
USB8_9
HD_AUDIO1
1
FLOPPY1
CD1
LAN
PHY
AUDIO
CODEC
Super
I/O
N68C-S
PCIE1
PCIE2
PCI1
PCI2
PWR_FAN1
Phenom II
AM2+/AM3
DDR2 1066
Dual Channel
RoHS
1
24
3
6
7
5
8
9
10
11
12
13
14
15
16
17
18
1920
21
22
23
24
25
26
27
28
29
30
USB 2.0
T: USB 0
B: USB1
Top:
RJ-45
Top :
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Mouse
PS2
Keyboard
VGA1
USB 2.0
T: USB2
B: USB3
COM1
1
LPT1
DDR3 1600

ASROCK N68C-S Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Number of Parallel ATA connectors	1
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	FCC, CE, WHQL
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP
Graphics card	GeForce 7025
Maximum graphics card memory	256 MB
RAID levels	0, 1, 0+1
Networking features	10/100 Mbps
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	208 mm
Width	244 mm
