BIOS SETUP UTILITY
Floppy Configuration
Select the type of
floppy drive
connected to the
system.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Floppy A
[1.44 MB 3 "]
1
2
BIOS SETUP UTILITY
Configure Super IO Chipset
Allow BIOS to Enable
or Disable Floppy
Controller.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
OnBoard Floppy Controller
Serial Port Address
Parallel Port Address
Parallel Port Mode
EPP Version
ECP Mode DMA Channel
Parallel Port IRQ
[Enabled]
[3F8 / IRQ4]
[378]
[ECP + EPP]
[1.9]
[DMA3]
[IRQ7]
3.4.63.4.6
3.4.63.4.6
3.4.6
Floppy ConfigurationFloppy Configuration
Floppy ConfigurationFloppy Configuration
Floppy Configuration
In this section, you may configure the type of your floppy drive.
3.4.73.4.7
3.4.73.4.7
3.4.7
Super IO ConfigurationSuper IO Configuration
Super IO ConfigurationSuper IO Configuration
Super IO Configuration
OnBoard Floppy Controller
Use this item to enable or disable floppy drive controller.
Serial Port Address
Use this item to set the address for the onboard serial port or disable it.
Configuration options: [Disabled], [3F8 / IRQ4], [2F8 / IRQ3], [3E8 / IRQ4],
[2E8 / IRQ3].
Parallel Port Address
Use this item to set the address for the onboard parallel port or disable it.
Configuration options: [Disabled], [378], and [278].
To Next Page
