ASROCK N68C-S User Manual

3838
3838
38
CHB ADDR/CMD Delay
Use this to adjust values for CHB ADDR/CMD Delay feature. Configuration
options: [Auto], [No Delay], [1/64CLK] to [31/64CLK]. The default value is
[Auto].
CHB ADDR/CMD Setup
Use this to adjust values for CHB ADDR/CMD Setup feature. Configuration
options: [Auto], [1/2CLK] and [1CLK]. The default value is [Auto].
CHB CS/ODT Delay
Use this to adjust values for CHB CS/ODT Delay feature. Configuration
options: [Auto], [No Delay], [1/64CLK] to [31/64CLK]. The default value is
[Auto].
CHB CS/ODT Setup
Use this to adjust values for CHB CS/ODT Setup feature. Configuration
options: [Auto], [1/2CLK] and [1CLK]. The default value is [Auto].
CHA CKE Drive
Use this to adjust values for CHA CKE Drive. Configuration options: [Auto],
[1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
CHA CS/ODT Drive
Use this to adjust values for CHA CS/ODT Drive. Configuration options:
[Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
CHA ADDR/CMD Drive
Use this to adjust values for CHA ADDR/CMD Drive. Configuration options:
[Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
CHA CLK Drive
Use this to adjust values for CHA CLK Drive. Configuration options: [Auto],
[0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA DATA Drive
Use this to adjust values for CHA DATA Drive. Configuration options: [Auto],
[0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA DQS Drive
Use this to adjust values for CHA DQS Drive. Configuration options: [Auto],
[0.75x], [1.00x], [1.25x] and [1.50x]. The default value is [Auto].
CHA Processor ODT
Use this to adjust values for CHA Processor ODT. Configuration options:
[Auto], [300 ohms], [150 ohms] and [75 ohms]. The default value is [Auto].
CHB CKE Drive
Use this to adjust values for CHB CKE Drive. Configuration options: [Auto],
[1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].
CHB CS/ODT Drive
Use this to adjust values for CHB CS/ODT Drive. Configuration options:
[Auto], [1.00x], [1.25x], [1.50x] and [2.00x]. The default value is [Auto].

ASROCK N68C-S Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Number of Parallel ATA connectors	1
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	FCC, CE, WHQL
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP
Graphics card	GeForce 7025
Maximum graphics card memory	256 MB
RAID levels	0, 1, 0+1
Networking features	10/100 Mbps
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	208 mm
Width	244 mm
