ASROCK PG27FF1A User Manual

15
Chapter 5 Connecting the Monitor
1. Turn off your computer.
2. Connect the video cable from the monitor to your computer.
3. Connect the power cord to the monitor power jack. (Figure A)
4. Plug the power cord into the electrical outlet. (Figure B)
5. Turn on the monitor. (Figure C)
6. Power on the computer and the monitor will auto detect the signal source.
7. Plug one end of the DisplayPort/HDMI cable to the monitor’s DisplayPort/HDMI port.
8. Connect the other end of the DisplayPort/HDMI cable to your computer's
DisplayPort/HDMI port.

ASROCK PG27FF1A Specifications

General

Color gamut	94 %
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	-
Native aspect ratio	16:9
Viewable size, vertical	336.312 mm
sRGB coverage (typical)	123 %
Contrast ratio (typical)	1100:1
Display number of colors	16.7 million colors
Viewable size, horizontal	597.888 mm
Digital vertical frequency	48 - 165 Hz
Digital horizontal frequency	30 - 183 kHz
Display brightness (typical)	250 cd/m²
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
AMD FreeSync type	FreeSync Premium
RMS rated power	4 W
Number of speakers	2
Product color	Black
Market positioning	Gaming
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	42 W
Power consumption (off)	0.3 W
Power consumption (standby)	- W
Power consumption (typical)	27 W
Power consumption (PowerSave)	0.5 W
Tilt angle range	23 - -5 °
Panel mounting interface	100 x 100 mm
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Package type	Box
Package weight	6230 g

Weight and Dimensions

Depth (with stand)	192.61 mm
Width (with stand)	612.42 mm
Height (with stand)	434.83 mm
Weight (with stand)	4480 g
Depth (without stand)	47.2 mm
Height (without stand)	367.03 mm
Weight (without stand)	3750 g
