ASROCK PHANTOM GAMING B650I LIGHTNING WiFi User Manual

40
Please refer to the table below for PLED (System Power LED) indications.
Serial ATA3 Connectors
(SATA3_1) (see p.6, No. 9)
(SATA3_2) (see p.6, No. 8)
ese two SATA3 connectors support SATA data cables for internal storage
devices with up to 6.0 Gb/s data transfer rate.
SATA3_1 SATA3_2
Status Description
Blinking (2Hz) Booting into system
On Booting completed
Blinking till BFG DRAM overclocking failed
On Booting without DRAM
Blinking (1Hz) Entering S3 sleep mode

ASROCK PHANTOM GAMING B650I LIGHTNING WiFi Specifications

General

Chipset	AMD B650
Form Factor	Mini-ITX
Memory Slots	2
Maximum Memory	64GB
Memory Type	DDR5
Memory Support	DDR5 6400+(OC)
PCIe Slots	1 x PCIe 4.0 x16
LAN	2.5 Gigabit LAN
CPU Socket	AM5
Bluetooth	Bluetooth 5.2
Audio Codec	Realtek ALC1220
Storage Interface	4 x SATA3 6.0 Gb/s
WiFi	WiFi 6E (802.11ax)
RGB Support	Yes
M.2 Slots	2
USB Ports	4 x USB 3.2 Gen1 Type-A, 2 x USB 2.0
