CPU_FAN1

Please note that this connector is the interface to the LED control board on the SR3, it requires the AMD

utility "SR3 Settings Soware" to control the LED.

*e diagram shown here are for reference only. Please refer to page 27 for the orientation of USB Header.

4-pin FAN cable

USB 2.0 Header
