ASROCK PRO BTC+ Series User Manual

X370 Pro BTC+
23
English
2.4 Expansion Slots (PCI Express Slots and Mining Ports)
ere are 8 PCI Express slots and 6 Mining ports on the motherboard.
PCIe slots:
PCIE1 (PCIe x16 slot) is used for PCI Express x4 lane width cards.
PCIE2/PCIE3/PCIE4/PCIE5/PCIE6/PCIE7/PCIE8 (PCIe x16 slot) is used for PCI
Express x1 lane width cards.
PCIe Slot and Mining Port Congurations
7
th
A-Series APUs:
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
PCIe Slot Mining Port
PCIE1
x4
M_Port1
x1
PCIE2
x1
M_Port2
N/A
PCIE3
x1
M_Port3
x1
PCIE4
x1
M_Port4
x1
PCIE5
x1
M_Port5
x1
PCIE6
x1
M_Port6
x1
PCIE7
x1
PCIE8
x1

ASROCK PRO BTC+ Series Specifications

General

Form Factor	ATX
CPU Socket	LGA 1151
Maximum Memory	32GB
Memory Slots	4
Storage Interface	6 x SATA3
USB Ports	6 x USB 2.0
LAN	1 x Gigabit LAN
Audio	7.1 CH HD Audio
M.2	1 x M.2
