ASROCK X299E-ITX/ac User Manual

English
53
X299E-ITX/ac
PCIE PLL Divider
Congure the PCIE PLL divider.
SRCO Source
Select CPU PLL or PCIE PLL as the SRCO source.
ClockGen Delay
Congure the delay at the beginning of Clockgen.
ClockGen GPIO
Congure the General-purpose input/output (GPIO) at the beginning of Clockgen.
Boot Performance Mode
Select the performance state that the BIOS will set before OS hando.
Intel Turbo Boost Technology
Intel Turbo Boost Technology enables the processor to run above its base operating
frequency when the operating system requests the highest performance state.
Intel SpeedStep Technology
Intel SpeedStep technology allows processors to switch between multiple frequen-
cies and voltage points for better power saving and heat dissipation.
Intel Speed Shift Technology
Enable/Disable Intel Speed Shi Technology support. Enabling will expose the
CPPC v2 interface to allow for hardware controlled P-states.
Intel Turbo Boost Max 3.0 Technology
Processors supporting the Intel Turbo Boost Max Technology 3.0 feature contain at least
one processor core whose maximum turbo frequency is higher than the others.
Adjust Pll
Adjust the Pll for higher -BCLK ration combination.
Change Pll Trim Value
Adjust the Pll value between +63 ro -63.
Change Pll Trim Prex
Adjust the Pll Trim Prex.
