Assa Abloy CU-200 - Page 2

89
10
12345
NO
COM
NC
(+) 24 V DC
QTST
PDET
PIMP
(-) 0 VDC
EXU-SI EXU-SA
12 3456789 01112131
1
ON
2345
(+) 24 V DC
OPEN
EXIT
OFF
UNL
KRST
KILL
KEY
O/C
OIMP
(-) 0 VDC
–
+
1
ON
2345
= DMPS monitoring and reference for KILL (NC)
= Presence detection (NC)/DMPS.SS
1)
= Presence impulse (NC)/DMPS.NS
1)
= Ground
External error indication
Open door indication
Monitoring of presence detection/DMPS.SS
Monitoring of presence impulse/DMPS.NS
No monitoring (both jumpers on)
Monitoring of presence detection and presence impulse
Blanking LED
Battery monitoring
Lock kick
1)
Lock release
2)
Locked without power (OFF) / with power (ON)
Lock 12 V (OFF) / 24 V (ON)
Automatic kill reset (jumper on)
Manual kill reset (jumper off)
Potentiometer for opening delay
= Unlocked signal from lock
= KILL reset (see jumper below)
= KILL impulse
= Key impulse (1,5-30 s)
= OPEN / CLOSE impulse (Latching relay)
= Outer impulse
= Ground
Electro-mechanical locking device (12 V DC
max. 1200 mA / 24 V DC max. 600 mA, see
DIP-switch No. 1 below)
Program selector
Battery
1)
Independent of switch position (ON /OFF), the “latch check” complies with
the ANSI 156.19 requirements.
Position OFF: Smooth closing, to be used on doors without lock.
Position ON: More powerful closing, to be used on doors with lock, to
overcome binding in the locking device.
2)
Door mounted sensor
2)
DMPS:
Relay 1:
Presence impulse (NC)
Relay 2:
Presence detection (NC)
1)
If not used strap to “Ground”.
2)
Remove strapping from terminals 2 and/or 3.
Blanking potentiometer
(Adjust the potentiometer to avoid
presence detection sensor to detect
the wall. Range 55 - 90 degrees.)
Relay output (“External error, KILL OUT
indication” or “Open/closed door
indication”, see above) 24 V, 1 A
Not to be used.
Remove strapping when connecting
to terminals 2 and/or 3.
Torx 10
Accessories
EXU-SI
EXU-SA
2 (2)
1007329-en-US
Electrical power
Tag strip:
Long = 2 pcs EXU
Short = 1 pc EXU
If the switch is set to ON, the LOCK RELEASE is active during the opening delay
time set by the potentiometer.
For “PAIR OF DOORS” installations, the “LOCK RELEASE” works in sequence:
First the primary then the secondary.
EXU-SA
EXU-SI
CU-200
5 mm nut driver
0.5 s
0 s
3 s
67
