ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
Optional Switches for Mortise Switch Plates
Model No. Description A B Comp Sub SNS
ASMKS SPDT Momentary NA NA 43.00 NA NA
ASMKSA SPDT Alternate (ON/OFF) NA NA 43.00 NA NA
ASMKS2 DPDT Momentary NA NA 71.50 NA NA
ASMKS2A DPDT Alternate (ON/OFF) NA NA 71.50 NA NA
Switch Position
for 90° Clockwise
(3 O’clock Activation)
Switch
(Momentary/Alternate)
Switch Assembly
Optional/Additional
Switch Position
for 90°
Counter-Clockwise
(9 O’clock Activation)
Or: 180° Individual
CW-CCW
(9 & 3 O’clock
Activation)
SPTD: 3-Wire (As Shown)
DPDT: 6-Wire (As Shown x 2 Pole Sets)
