ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
Padlocks
Model No. Description A B C D Comp Sub SNS
T
win V-10
V65190B No.2 Non-Key-Retaining 88.00 80.50 73.50
V65190LB No.2 Non-Key-Retaining Ext. Shackle 94.00 86.50 79.50
V65190SB No.2 Non-Key-Ret. w/Shrouded Shackle 102.00 95.00 88.00
V65191B No.2 Key-Retaining 88.00 80.50 73.50
V65191LB No.2 Key-Retaining Ext. Shackle 94.00 86.50 79.50
V65391B No.3 Key-Retaining 162.00 154.50 147.50
V65391SB No.3 Key Ret. w/Shrouded Shackle 169.00 161.50 154.50
V65591SB No.5 Key Ret. w/Shrouded Shackle 283.00 275.50 268.50
Twin Exclusive
E65190B No.2 Non-Key-Retaining 88.00 80.50 73.50
E65190LB No.2 Non-Key-Retaining Ext. Shackle 94.00 86.50 79.50
E65190SB No.2 Non-Key-Ret. w/Shrouded Shackle 102.00 95.00 88.00
E65191B No.2 Key-Retaining 88.00 80.50 73.50
E65191LB No.2 Key-Retaining Ext. Shackle 94.00 86.50 79.50
E65391B No.3 Key-Retaining 162.00 154.50 147.50
E65391SB No.3 Key Ret. w/Shrouded Shackle 169.00 161.50 154.50
E65591SB No.5 Key Ret. w/Shrouded Shackle 283.00 275.50 268.50
Twin 6000 Classic
65190B
No.2 Non-Key-Retaining
103.00
94.00
85.00
65190LB No.2 Non-Key-Retaining Ext. Shackle 110.00 101.00 92.00
65190SB
No.2 Non-Key-Ret. w/Shr
ouded Shackle
120.00
111.00
102.00
65191B No.2 Key-Retaining 103.00 94.00 85.00
65191LB No.2 Key-Retaining Ext. Shackle 110.00 101.00 92.00
65391B No.3 Key-Retaining 184.00 175.00 166.00
65391SB No.3 Key Ret. w/Shrouded Shackle 192.50 185.00 178.00
65591SB No.5 Key Ret. w/Shrouded Shackle 322.00 314.50 307.50
1.900 1.100 0.940 0.315
1.900 2.035 0.940 0.315
1.900 0.535 0.475 0.315
1.900 1.100 0.940 0.315
1.900 2.035 0.940 0.315
2.450 1.235 1.295 0.395
2.450 0.710 0.590 0.395
3.150 0.985 0.830 0.550
1.900 1.100 0.940 0.315
1.900 2.035 0.940 0.315
1.900 0.535 0.475 0.315
1.900 1.100 0.940 0.315
1.900
2.035 0.940 0.315
2.450 1.235 1.295 0.395
2.450 0.710 0.590 0.395
3.150 0.985 0.830 0.550
1.900 1.100 0.940 0.315
1.900 2.035 0.940 0.315
1.900 0.535 0.475 0.315
1.900 1.100 0.940 0.315
1.900 2.035 0.940 0.315
2.450
1.235 1.295 0.395
2.450 0.710 0.590 0.395
3.150
0.985
0.830
0.550
B
A
CD
#2 #2
Extended
Shackle
#2
Shrouded
#4-5
Shrouded
#3
