Cams & Tailpieces
Cams & Tailpieces
Model # Description R-A R-B Package Qty. Price
867445 #1 Adams Rite Cam 0.118 0.555 10 4.50/ea
867452 #2 Sargent Cam N/A 0.709 10 4.50/ea
867446 #3 Corbin Clover Leaf Cam 0.114 0.602 10 4.50/ea
867447 #4 Corbin Beaver Tail Cam N/A 0.732 10 4.50/ea
872610 #5 Yale/Standard Cam N/A 0.709 10 4.50/ea
867453 #6 Schlage “L” Cam 0.124 0.516 10 10.50/ea
805412 #7 Segal Type Cam N/A 0.779 10 10.50/ea
806471 #8 Jumbo Corbin Cam N/A 0.914 10 10.50/ea
907306 #9 Best 30H Series 0.114 0.602 10 10.50/ea
353445 #10 Airteq/Norment Cam N/A 0.787 10 5.00/ea
809337 #11 Airteq/Norment Mogul Cam N/A 1.165 10 10.50/ea
354945 #12 Corbin Jumbo Clover Leaf Cam 0.114 0.828 10 10.50/ea
355849 #13 Sargent Short Cam N/A 0.515 10 10.50/ea
355850 #14 Sargent Mogul N/A 1.043 10 10.50/ea
872612 #15 Yale Replacement Cam 0.742 0.308 10 10.50/ea
867450 Horizontal & Vertical Rim Tailpiece kit 16.50/ea
867451 Lazy-motion Rim Tailpiece kit 16.50/ea
868958 Schlage KIK Plug Cap 10 2.25/ea
868959 Schlage KIK Plug Cap Spring 100 .50/ea
868960 Schlage KIK Plug Cap Pin 100 .25/ea
804877 Schlage Break-off Tailpiece 10 4.25/ea
868654
Corbin New Style Standar
d-duty T
ailpiece
100
2.00/ea
868624 Rollpin - Corbin 10 .25/ea
868231 Cylinder Plug Retaining Ring 100 .50/ea
900250
Sargent 6-line, Arrow Tailpiece (short) 2.25/ea
900251 Sargent 6-line, Arrow Tailpiece (long) 2.25/ea
900252
Sar
gent 6-line, Arrow Tailpiece retaining ring .50/ea
900253 Sargent/Arrow Tailpiece (Med.) 1.75/ea
900254 Sargent 11-line T-Zone Tailpiece 4.25/ea
900256 Yale Key-In-Lever Tailpiece 6.00/ea
900257
Y
ale Key-In-Lever Roll Pin
2.00/ea
867045
Oval Cylinder Tailpiece 50 3.00/ea
803169 Oval Cylinder Tailpiece, 505 Lock Function 7.50
867046 Tailpiece Washer 50 3.50/ea
867090 Phillips Screws for Cams, Mortise & Oval Tailpiece 100 1.00/ea
868138
Slotted Screws for Rim Tailpiece 100 .75/ea
868134 Tail Extension for Rim Cylinder 8.00
867109
Br
eak-off Tailpiece for V/H Rim Cylinder 6.00
868136 Lazy Motion Tailpiece for Rim Cylinder 5.75
868135
Lazy Motion T
ailpiece W
asher 3.50
#14
H/V
L
Tailpieces
An ASSA ABLO
Y Group compan
y
134
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO
#11 #12 #13 #15
#1 #2 #3 #4 #5
#6
#7
#8
#9 #10
Cam Key:
R-A
– Head Radius • R-B – Overall Radius
