Assa Abloy Yale YRD256 - Install Touchscreen Escutcheon; Escutcheon Placement on Door; Bolt Position for Escutcheon

P/N - - Rev DYRL SLKFTSINSTL FUL
4
2
Installing Touchscreen Escutcheon
Outside of DoorInside of Door
Bolt must be in retracted
(unlocked) position. Note
horizontal orientation of
mechanism.
!
