Associated Electrics RC8B3.1 - Radio Tray Build - Continued; Radio Tray Build - Step 2; Radio Tray Build - Step 3

21
:: Radio Tray Build - Bag 10.1, 10.2, 10.3 - Step 4
:: Radio Tray Build - Bag 10.1, 10.2, 10.3 - Step 3
:: Radio Tray Build - Bag 10.1, 10.2, 10.3 - Step 2
25201
3x8mm
FHCS
31531
3x6mm
BHCS
81103
Receiver
Battery
Tray
6727
Servo
Tape
x2
x3
25187
3x14mm
BHCS
89218
3x8mm
Washer
89218
3x8mm
Washer
89023
Servo
Spacer
89023
Servo
Spacer
25187
3x14mm
BHCS
25201
3x8mm
FHCS
31448
2.5x8mm
FHCS
x4
x4
x4
x2
x2
x4
x2
81102
Transponder
Mount
Strapping Tape
not included!
Receiver Battery
not included!
Transponder
not included!
Servo not
included!
Servo not
included!
Racer’s Tip:
Use strapping tape
for extra security for
battery installation!
When spacing your
servos, make sure the
servo does not touch
the chassis when
installed.
!
