Associated Electrics RC8B3.1 - Page 22

22
:: Radio Tray Build - Bag 10.1, 10.2, 10.3 - Step 5
:: Radio Tray Build - Bag 10.1, 10.2, 10.3 - Step 6
81102
Receiver
Box Lid
31448
2.5x8mm
FHCS
x6
6727
Servo
Tape
6338
Antenna
Tube and
Cap
25225
3x3mm
Set Screw
Receiver
not included!
When using a receiver
switch, you will need to
carefully remove
material from the
receiver box lid in the
highlighted sections
below in order to
mount your switch.
!
89214
4x12mm
FHCS
x5
