:: :: Shocks BuildShocks Build - - Bag Bag 2.12.1 - Step 4
The springs come with
a colored marking
pre-installed for easy
identification
!
81194
Spring
Cup,
20mm
81221
Spring
Collar O-Ring,
20mm
81221
Spring
Collar, 20mm
81225
V2 Front Spring,
Blue (5.50lb/in)
81231
V2 Rear Spring,
Blue (4.30lb/in)
shock
fluid
:: :: Shocks BuildShocks Build - - Bag Bag 2.12.1 - Step 3- Step 3
:: :: Shocks BuildShocks Build - - Bag Bag 2.12.1 - Step 2- Step 2
When installing the
shock bladder, make
sure it is correctly
seated within the
shock cap as shown.
Leave a gap
when
installing the
shock cap.
Fill to top of
shock body.
!
!
!
shock
fluid
Front Shock Fluid:
35wt #5429
Rear Shock Fluid:
30wt #5422
Front Shock Fluid:
Rear Shock Fluid:
81453
Bladder,
Stiff
81452
RC8B3.2
Shock Cap
81181
Shock Cap
Insert
91492
2x4mm
BHCS
91492
Gasket
81194
Shock
Rod End
and Ball
81190
Shock
Boots
Racer’s Tip:
Use green slime
(#1105) to
lube the o-rings
before installation!
81181
Shock Cap
Insert
Compress shock shaft fully.
Let shock fluid bleed from
bleeder screw hole, then
tighten the screw.
For more rebound, do not
compress shock shaft as far
before tightening the
shock cap.
!
