ASTEC JCI LS Series User Manual

REFERENCE # 450242
12/8/06Rev. M
Lower Assembly 1200LS
JCI 24/7 Parts Number 888-474-0115
© 2006 JCI
PAGE 9
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
1 1 450243 ASSY PL WEDGE 1200 LS
2 1 450244 ASSY CONE 1200 LS/SS
3 1 450268 ASSY PINION 1200 LS
4 1 450043 RING SEAL BASEFRAME
5 4 450068 PIN PUSH BASEFRAME
6 4 084009 O-RING 6227-27
7 1 450497 PL FLOATING W/ INSERTS
8 1 406087 SHAFT CONE BRAKE
9 1 546467 PIN CLUTCH ASSEMBLY
11 1 450166 PL THRUST
12 1 406109 PL CONE BRAKE
14 1 406014 RING GUIDE CLUTCH
15 1 450227 CVR BRAKE HOUSING 1200
16 3 540129 ROLLER SHIM GUARD
17 8 450069 BOLT ADJ CONNECT QUICK
18 1 450485 ASSY HEATER 2000W 120V
19 1 450603 BASEFRAME MACH (SEE TEXT)
22 2 406110 SHAFT KEY BRAKE
25 4 070130 CAPSCREW HEX 5/16 24NF X 3/4
26 4 070203 CAPSCREW SOC 5/16-18NC X 1-1/2
27 6 070152 CAPSCREW HEX 1 14NF X 3
28 32 070027 CAPSCREW HEX 1/2 13NC X 1-1/4
29 4 070141 SETSCREW SOC 5/8 11NC X 5/8
30 8 450148 CPLR BOLT ADJ 2 SPLITS
31 8 070010 CAPSCREW HEX 5/8 11NC X 1-3/4
32 8 540226 RETAINER ADJ BOLT
33 8 450126 WASHER BOLT ADJ
34 3 070016 CAPSCREW HEX 1/2 13NC X 1-1/2
35 8 084065 O-RING PARK 2-329 2.375 OD
36 4 540222 BASEFRAME STRUT GUARD
37 1 083024 5502-12-12
39 1 083033 PIPE SCH 40 1-1/4 X 26 NPT
40 1 083032 ELBOW SCH 40 1-1/4 NPT 90
41 1 540243 BRKT FILL PIPE
42 1 540191 DIPSTICK
43 1 450157 KEY DRIVE SHEAVE
44 1 620150 ARROW
45 32 078025 WASHER LOCK 1/2
46 8 078014 WASHER LOCK 5/8
