JCI 24/7 Parts Number 888-474-0115
© 2005 JCI
PAGE 25
12/8/06Rev. D
REFERENCE # 456169
Lube Panel J-Box Assembly
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
1 1 020136 BOX,HOFFMAN,A-806 CHNF,8.0X6.0
2 1 020137 PANEL, HOFFMAN, A-8P6
3 12 020500 TERM BLOCK (J4) AB1492-J4
4 2 020512 END STOP AB1492-EAJ35
5 4.75 020182 DIN MOUNTING RAIL, DIN #3
6 2 020510 END PLATES AB 1492-EBJ3
7 0.5 020103 GROUND BAR KIT, 14 POS
8 1 020505 CENTER JUMPER,2POLE (J4)
9 1 020145 TERMINAL BLOCK NO. TABS 0-9
10 2 070341 MACH SCREW RD HD 10-24 x .500
11 2 076072 NUT, 10-24 NC
