ASTEC JCI LS Series User Manual

REFERENCE # 450485
06/19/03Rev. A
Heater Assembly 2000W 120V
JCI 24/7 Parts Number 888-474-0115
© 2003 JCI
PAGE 18
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
1 1 4 5 0 2 5 4 H E AT E R C O V E R W E L D M E N T
2 1 5 4 0 3 2 7 H E AT E R M A C H I N E D , 2 0 0 0 W, 1 2 0 V
3 1 5 4 0 2 9 4 H E AT ER ELECTRICAL BOX COVER
4 1 0 2 0 0 2 6 T H E R M O O N 6 0 D E G O F F 8 0 D E G.
5 2 540254 GASKET, HEATER
6 4 070032 CAP SCREW HEX 3/8 16NC X1-1/4
7 2 070008 CAP SCREW HEX 3/8 16NC X1G5
8 1 076042 NUT 1-1/2-6NC
9 1 070056 MACH SCREW RD HD #8-32NC X 3/4
1 0 2 0 2 0 0 3 6 L U G, T & B C - 1 0 - 8
11 2 020037 CONNECTOR 3/4X90 FITS 3/4 FLEX
12 192 020033 CONDUIT, 3/4 FLEX, NON-METALLI
1 3 2 0 2 0 0 4 1 D I S C O N N E C T F E M 1 0 - 1 2 G A , N Y L O N
1 4 2 0 2 0 0 4 2 D I S C O N N E C T F E M 1 4 - 1 6 G A , N Y L O N
15 2 020043 DISCONNECT MALE 14-16GA NYLON
16 196 020028 WIRE, 10 GA THHN, WHITE
17 196 020029 WIRE, 10 GA, THHN RED
18 196 020030 WIRE, 16 GA MTW BLACK
19 196 020031 WIRE, 16 GA MTW BLUE
20 196 020032 WIRE, 16 GA MTW GREEN
21 1 076046 NUT, #8-32NC
2 2 1 0 7 8 0 3 7 W A S H E R , L O C K , # 8
23 4 078024 WASHER, LOCK, 3/8
24 2 020018 SEALING RING 5263
25 2 020019 LOCKNUT, RID METAL CON, 3/4 T
26 1 080032 PLUG, MAGNETIC 1
