REFERENCE # 450197
07/29/03Rev. F
External Lube Panel Assembly 1200LS
JCI 24/7 Parts Number 888-474-0115
© 2003 JCI
PAGE 22
ITEM QTY
PART
NUMBER
DESCRIPTION COMMENTS
1 1 060033 MTR 2HP1800TEFC60HZ 145T TOS
2 1 080024 PUMP, LUBE .761 CU IN/REV
3 1 089005 COUP LUBE ASSY LOVEJOY L090, S
4 1 080030 PUMP ADAPTOR (FIL-4AA)
5 1 085004 FILTER ASSY, DONALDSON HAK05
6 1 456154 EXT LUBE PANEL
7 1 080027 FLOW SWITCH, 54
8 1 450187 HORN ASSY, 115V - NO PROJECTOR
9 1 456169 J-BOX 110V/60HZ 8.0 X 6.0
10 1 082064 HOSE 1/2X28.5 1/2MX1/2M SWIVEL
11 2 083527 BUSHING 1-1/2 NPT X 3/4 NPT
12 1 083030 PIPE NIPPLE 3/4X1/2FF 0101-8-1
13 2 083191 TEE,FEMALE 3/4 HP, 022T-12-12
14 1 080034 REDUCER 3/4P-1/4P HP 0102-12-4
15 1 083026 5502-04-02, ST ELBOW 1/4X1/8
16 1 083016 SAMPLER PLUG
17 1 090114 THERM, 40-240F, 5' CAPILLARY
18 1 083005 5502-08-08, ST ELBOW 90D 1/2
19 1 083024 5502-12-12, ST ELBOW 3/4
20 1 083067 5405-12-16 ADAPTER, PIPE
21 1 080043 COVER PLATE PUMP ADAPTOR
22 1 083074 OIL SAMPLER NEEDLE W/TUBIN
23 1 020027 CONNECTOR, 3/4 X 90 T&B 2272
24 4 070224 CAPSCREW SOC 5/16 18NC X 1-1/4
25 4 076022 NUT, 5/16-18NC
26 4 078023 WASHER, LOCK, 5/16
27 4 070066 CAP SCREW HEX 5/16-18NC X3/4
28 4 076027 NUT, NYLOCK 5/16-18NC
29 4 070009 CAP SCREW HEX 3/8 16NC X3/4G5
30 2 070056 MACH SCREW RD HD #8-32NC X 3/4
31 8 078024 WASHER, LOCK, 3/8
32 4 070008 CAP SCREW HEX 3/8 16NC X1G5
33 6 070062 CAP SCREW HEX 1/4 20NC X 1 G5
34 6 076026 NUT, NYLOCK 1/4-20NC
35 6 078015 WASHER, FLAT, 1/4
36 2 020019 LOCKNUT, RID METAL CON, 3/4 T
37 2 020018 SEALING RING 5263
38 1 083025 ST ELBOW 3/4X1/2 CD 2102-8-12
39 40 020034 WIRE, S/O, 16/4
