NOTE:Second sensor is normally supplied for reject flow sensing.
This can however be assigned as the inlet sensor. To change the
factory settings, contact nearest dealer or supplier.
9
Recovery can be calculated by the formula:
Permeate flow Rate (PR)
% Recovery =
Permeate flow rate(PR) + Reject flow rate (RR)
The relay will get energized, if actual recovery exceeds the set
value.
HOW TO SET THE FLOW COMPARATOR:
KEY TO BE PRESSED
DISPLAY
Menu
View settings
The display scrolls through all the
settings of meter and comes to
Change Settings?
Menu
CH1 SETTINGS
Menu
RECOVERY: _ _ _ _ previously set
value
Set required recovery quantity by using scroll & select ch key
Menu
HYSTERESIS:_ _ _ _ previously set
value
Set required Hysteresis using scroll & select ch key
Menu
QUIT
Menu
Display scrolling
Menu
Auto
Auto can be changed to manual by select ch key & vice versa
Menu
EXIT
Menu
IN CASE OF 4-20mA OUTPUT:
In case of transmitter,meter takes the sensor input
& gives 4-20mA output current.Factory settings for ZERO
(value of flow at which transmitter would give 4 mA current) & SPAN
(value of flow at which transmitter would give 20 mA current) are:
Reading
4mA
20mA
Current Output(mA)
00.00
X 100
