viron xt pumps Installation Manual
24
viron xt pumps Installation Manual
9.2 Model P320XT and P520XT Spare Parts List
Item # Description Part # Quantity
1 LID COMPLETE WITH O-RING 40089 1
2 LID O-RING 70006 1
3 BASKET 40065 1
4 PIPE FITTING COMPONENT BAG 78303 1
5 CHECK VALVE ASSEMBLY 598770 1
6 PUMP WET END 40097 1
7 O-RING 70003 2
8 O-RING FOR DIFFUSER 78104 1
9 DIFFUSER – XT 320 40071A 1
9 DIFFUSER – XT 520 40071B 1
10 IMPELLER – P320 40060X 1
10 IMPELLER – P520 40060Z 1
NOT SHOWN IMPELLER RETAINING BOLT 78187 1
NOT SHOWN O-RING 78711 1
11 MECHANICAL SEAL 75509 1
12 O RING (SEAL PLATE) 70022 1
13 SEAL PLATE 40098 1
14 SEAL PLATE TO WET END BOLTS 78772 6
15 MOTOR RETAINING BOLT 40156 4
16 MOTOR FOOT 4005002 1
16 MOTOR FOOT RUBBER INSERT 40056 1
17 MOTOR PLASTIC FAN COWL 70600 1
18 CONTROLLER REAR COVER 70603 1
18 REAR COVER RETAINING SCREWS 40145 2
19 MOTOR COOLING FAN 40285 1
19 RETAINING CLIP –COOLING FAN 40285C 1
20 CONTROLLER – P320 21488 1
20 CONTROLLER – P520 21489 1
21 DRAIN PLUG 7820702 2
21 O-RING 78103 2
22 MOTOR – P320 71460 1
22 MOTOR – P520 71462 1
23 CONTROLLER LABEL LABEL311 1
NOT SHOWN XT LABEL LABEL518 1
NOT SHOWN PIPE FITTING COMPONENT BAG 78303 1
