Section 2. General Information
This manual provides installation and operation
instructions for the AstralPool Viron XT pumps.
Read the installation and operation instructions
completely before proceeding with the
installation.
2.1 Technical Assistance
Web:
www.astralpool.com.au
Phone:
1300 186 875
2.2 General Operation Description
Ideal for the average sized pool, the P320 XT has a
flow rate sufficient to back wash up to 30” or 800mm
diameter sand filters, provide a powerful vacuum
when cleaning the pool and drive up to 6 spa jets.
The large liquid crystal display clearly shows the RPM
of the motor and enables adjustment of the start up
priming time, priming flow rate, and visual display
of each speed setting. The inbuilt 24 hour timer is
easily enabled and provides up to four time periods
each day with different speed settings to provide the
perfect flow rate for your pool. In addition, special
applications such as in floor cleaning or programming
water features are enabled using the time clock and
speed selection for different times of day.
The P520 XT provides high flow and high pressure and
also incorporates electronic power factor correction
which provides even further reductions in power
consumption, even on maximum speed.
• Continuous duty rated motor
• Precision reinforced moulded high head impeller,
giving extra performance
• Single piece moulded body for added strength and
longer life
• Rapid priming diuser quickly corrects loss of water
ow
• Quick and easy disassembly for servicing
• Large capacity basket with easily removed ramp on lid
• Ability to adjust factory pre-set speeds for optimum
water ow and maximum energy savings for your pool
and its equipment.
• Double Insulated water circuit for maximum electrical
protection
2.3 Flow Rate Specification
Model P320 XT P520 XT
High Flow Rate
(2850 RPM)
320 lpm 520 lpm
Medium Flow Rate
(2000 RPM)
206 lpm 426 lpm
Low Flow Rate
(1325 / 1125 RPM)
128 lpm 200 lpm
2.4 Dimensions
252mm
338mm
Figure 1. Front Dimensions
217mm
289mm
646mm
266mm
Figure 2. Side Dimensions
