ASTRO AMC-2000 User Manual

Page 14
STAND WITH PUMP
KEY
PART NO.
DESCRIPTION
QTY.
1.
156-102-18
ELEVATOR BRACKET
2
2.
123-0017
SCREW, 10-32 x 1/4 PH, TRUSS
32
3.
156-103-05
PANEL – BASE, PUMP COVER
1
4.
156-103-07
SIDE PLATE R/H
1
5.
156-103-06
SIDE PLATE L/H
1
6.
156-103-25
ELEVATOR BRACKET SUPPORT
2
7.
123-0695
SPRING PIN, 3/32 x 1/2
1
8.
156-103-27
COLLAR
1
9.
123-0841
CARRIAGE BOLT, 5/16 -18 x 1
4
10.
156-103-12
HELIX ANGLE WORM
2
11.
156-103-11
WORM GEAR 20 TEETH
1
12.
123-0018
ROLL PIN, 1/8 x 3/4 – BLACK
3
13.
156-103-08
SPROCKET 25B13
2
14.
156-103-09
IDLER PULLEY
2
15.
156-103-21
WORM SHAFT
1
16.
123-0135
KNOB
2
17.
156-103-20
DRIVE SHAFT
1
18.
156-103-26
CHAIN, TRANSMISSION ROLLER
2
19.
123-0200
CONNECTING LINK, CHAIN
4
20.
156-103-23
ELEVATOR BRACKET SUPPORT
2
21.
86-103-04
COVER, SIDE PANEL
2
22.
156-103-03
SIDE PANEL, L/H
2
23.
123-0293
KNOB, HEIGHT ADJUSTMENT
1
24.
86-103-06
PUMP COVER, STAND
2
25.
123-0707
RUBBER GROMMET, 1/2 ID x 3/4 OD
1
26.
156-103-04
SIDE PANEL, R/H
1
27.
123-0143
SCREW, HEX 1/4-20 x 5/8
4
28.
123-0063
WASHER, PLAIN 1/4 -MOTOR & PUMP
8
29.
123-0064
LOCK WASHER, 1/4
8
30.
123-0054
NUT, HEX 1/4-20
8
31.
123-0517
CASTER, NON-LOCKING
2
32.
123-0521
CASTER, LOCKING
2
33.
86-103-31
BASE WELDMENT
1
34.
84-103-07
VACUUM PUMP ASSEMBLY, 115V
1
35.
123-0131
CLAMP, HOSE
1
36.
84-106-41
HOSE, PUMP
1
37.
123-0051
NUT, HEX 5/16-18
4
38.
123-0757
SET SCREW, 6-23 x1/4 STD CUP PT
4
39.
123-0855
LOCKING WASHER, 5/16
4
* 40.
84-140-78
RELAY BOX 220V / 50 Hz
1
* 41.
123-0436
TRANSFORMER, 220V / 50 Hz
1
* 42.
84-103-10
VACUUM PUMP, 220V / 50 Hz
1
43.
56-108-22
THUMBSCREW
1
44.
123-0096
WASHER, PLASTIC 3/8 x 3/4 x 1/16
2
45.
123-0311
WASHER, PLASTIC 9/32 x 3/4 x 1/16
2
46.
123-0701
SCREW, 10-32 x 3/16 PH TRUSS HD
4
47.
123-0034
ROLL PIN, 1/8 x 5/8
1
*48.
123-0050
NUT, 10-32 x 5/16 HEX ZINC
6
*49.
123-0024
SCREW, 10-32 x 3/8 PH TRUSS HD MS ZINC
6
*50.
123-0237
STAR WASHER, #10 EXTERNAL
6
*51.
123-0262
WASHER, #10 3/16 x 3/8 x .032
6
52.
123-0312
WASHER, PLASTIC 5/16 x 1/2 x .030
2
53.
123-0145
FITTING
1
**
K247
SERVICE KIT, OLD STYLE PUMP
**
K478
SERVICE KIT, NEW STYLE PUMP
**
AK524
FELT, NEW STYLE PUMP ONLY
* ITEMS 40, 41, 42 ARE FOR 220V / 50 Hz ONLY.
** PARTS NOT SHOWN.
