AstroAI DT201D User Manual

-
11
-
The built-in buzzer will
sound if the resistance is
less than about 30Ω.
Open circuit
voltage: about
0.5V
Overload Protection: 250V DC/AC RMS
For continuity test: When the resistance is between 30Ω and
100Ω, the buzzer may sound or may not sound. When the
resistance is more than 100Ω, the buzzer won’t sound.
5-7.1 FREQUENCY (Auto Ranging)
Range
Accuracy
0 ~ 60MHz
±(1.0% of rdg + 5dgts)
5-7. 2 FREQUENCY ( through clamp )
Range
Accuracy
50 ~ 1KHz
±(1.5% of rdg + 5dgts)
5-8. CAPACITANCE (Auto Ranging)
Range
Accuracy
60nF/600nF/6uF
60uF/400uF/20mF（10sec）
±(8.0% of rdg + 5dgts)
5-9. DUTY CYCLE
Range
Resolution
Accuracy
0.01%~99.9%
0.01%
±1%
For value between 10% and 90% duty cycle at 50Hz.
6. OPERATION INSTRUCTION
6-1. Measuring Voltage
1) Connect the BLACK test lead to the “COM” jack and
the RED to the “v” jack.
2) Set the function switch to V or V range.
3) Connect the test leads across the source or load to be

AstroAI DT201D Specifications

General

Brand	AstroAI
Model	DT201D
Category	Measuring Instruments
Language	English
