ASUS A8V-VM 2-23
2.4.4 Onboard Devices Configuration
Congure Win627EHF Super IO Chipset
Serial Port Address [2F8/IRQ3]
Serial Port Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
LDT to AGP Lokar Frequency [Auto]
LDT to AGP Width (Upstream) [16 BIT]
LDT to AGP Width (Downstream) [16 BIT]
HyperTransport Configuration
LDT to AGP Lokar Frequency [Auto]
Sets the LDT to AGP frequency.
Conguration options: [Auto] [200 MHz] [400 MHz] [600 MHz] [800 MHz]
[1000 MHz]
LDT to AGP Width (Upstream) [16 BIT]
Allows you to select LDT Lokar upstream width.
Conguration options: [8 BIT] [16 BIT]
LDT to AGP Width (Downstream) [16 BIT]
Allows you to select LDT Lokar downstream width.
Conguration options: [8 BIT] [16 BIT]
AMD CoolN Quiet Configuration
Enables or disables the Cool’N Quiet Conguration.
PCI Delay Transaction [Enabled]
Enables or disables PCI Delay Transaction.
Serial Port Address [2F8/IRQ3]
Allows you to select the Serial Port base address.
Conguration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4]
[2E8/IRQ3]
