Asus AAEON UP Squared Pro 7000 User Manual

Chapter 1 – Product Specifications 2
Maker Board UP Squared Pro 7000
UPN-ADLN01
1.1 Specifications
System
Processor
Intel® Core™ i3-N305
Intel Atom® x7425E
Intel® Processor N97
Intel® Processor N50
(formerly Alder Lake N)
Graphics
Intel® UHD Graphics for 12
th
Gen Intel® Processors
Memory
Up to 16GB LPDDR5
Storage
Up to 64GB eMMC
I/O
HDMI 2.0b x 1
DP 1.2 x 1
DP 1.2 x 1 (via USB Type-C)
Audio Jack x 1 (Mic-In + Line-Out)
RS-232/422/485 x 2 (from 10-pin header)
Camera
—
USB
USB 2.0 x 2 (from 10-pin header x 1)
USB 3.2 Gen 2 x 2 (Type-A)
USB 3.2 Gen 2 x 1 (Type-C)
Expansion
40 pin GPIO x 1
M.2 2230 E-Key x 1 (CNVI, PCIe Gen 3 [x1], USB 2.0)
M.2 2280 M-Key x 1 (PCIe Gen 3 [x2])
M.2 3052 B-Key x 1 (USB 3.2 Gen 2 only)
SATA III x 1
Display Interface
HDMI 2.0b x 1
DP 1.2 x 1
DP 1.2 x 1 (via USB Type-C)
