2-4 Chapter 2: Hardware information
2.2.4 Layout contents
Slots Page
1. DDR2 DIMM slots 2-14
2. PCI slots 2-22
3. PCI Express x16 slots 2-22
Jumper Page
1. Clear RTC RAM (3-pin CLRTC_EN) 2-23
Rear panel connectors Page
1. PS/2 mouse port (green) 2-25
2. Coaxial S/PDIF Out port 2-25
3. LCD Poster 2-25
4. LAN 2 (RJ-45) port 2-25
5. LAN 1 (RJ-45) port 2-25
6. USB 2.0 ports 1 and 2, 3 and 4 2-26
7. IEEE 1394a port 2-26
8. Optical S/PDIF Out port 2-26
9. PS/2 keyboard port (purple) 2-26
Supreme FX Page
1. Line In port (light blue) 2-26
2. Line Out port (lime) 2-26
3. Microphone port (pink) 2-26
4. Center/Subwoofer port (orange) 2-26
5. Side Speaker Out port (gray) 2-26
6. Rear Speaker Out port (black) 2-26
