4-18
Chapter 4: BIOS setup
Refer to the CPU documentation before setting the CPU Vcore voltage. Setting
a high Vcore voltage may damage the CPU!
FSB Termination Voltage [Auto]
Allows you to select the front side bus termination voltage.
Conguration options: [Auto] [1.200V] [1.250V] [1.300V] [1.350V] [1.400V] [1.450V]
[1.500V] [1.550V]
Setting a high FSB termination voltage may damage the chipset and CPU.
NB VCore [Auto]
Conguration options: [Auto] [1.250V] [1.275V] [1.300V] [1.325V] [1.350V] [1.375V]
[1.400V]~[1.900V] [1.925V] [1.950V] [1.975V] [2.000V] [2.025V]
Memory Voltage [Auto]
Allows you to select the DDR2 reference voltage.
Conguration options: [Auto] [1.800V] [1.825V] [1.850V] [1.875V] [1.900V] [1.925V]
[1.950V] [1.975V] [2.000V] [2.025V] [2.050V] [2.075V] [2.100V] [2.125V] [2.150V]
[2.175V] [2.200V]~[3.200V] [3.225V] [3.250V] [3.275V] [3.300V] [3.325V] [3.250V]
[3.375V]
Refer to the DDR2 documentation before adjusting the memory voltage. Setting
a very high memory voltage may damage the memory module(s)!
DDRII Channel A REF Voltage [Auto]
Conguration options: [Auto] [DDRII_REF-30mv] [DDRII_REF-20mv]
[DDRII_REF-10mv] [DDRII_REF] [DDRII_REF+10mv] [DDRII_REF+20mv]
[DDRII_REF+30mv]
DDRII Channel B REF Voltage [Auto]
Conguration options: [Auto] [DDRII_REF-30mv] [DDRII_REF-20mv]
[DDRII_REF-10mv] [DDRII_REF] [DDRII_REF+10mv] [DDRII_REF+20mv]
[DDRII_REF+30mv]
DDRII Controller REF Voltage [Auto]
Conguration options: [Auto] [DDRII_REF-30mv] [DDRII_REF-20mv]
[DDRII_REF-10mv] [DDRII_REF] [DDRII_REF+10mv] [DDRII_REF+20mv]
[DDRII_REF+30mv]
SB Vcore (SATA,PCIE) [Auto]
Conguration options: [Auto] [1.50V] [1.55V] [1.60V] [1.65V] [1.70V] [1.75V] [1.80V]
[1.85V]
