Chapter 4: BIOS setup
The onboard hardware monitor automatically detects the optional fan speed and
the voltage output. If the fan is not connected to the motherboard, the eld shows
N/A.
CPU Fan Prole [Optimal]
Allows you to set the appropriate performance level of the CPU Q-Fan. When
set to [Optimal], the CPU fan automatically adjusts depending on the CPU
temperature. Set this item to [Silent Mode] to minimize fan speed for quiet CPU fan
operation, or [Performance Mode] to achieve maximum CPU fan speed.
Conguration options: [Optimal] [Silent Mode] [Performance Mode][Optimal] [Silent Mode] [Performance Mode][Performance Mode]
Chassis Fan 1/2/3 Speed [xxxxRPM] or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the chassis
fan speed in rotations per minute (RPM). If the fan is not connected to the
motherboard, the eld shows N/A.
Chassis Q-Fan Control [Disabled]
Allows you to enable or disable the chassis Q-Fan controller.
Conguration options: [Disabled] [Enabled]
The Chassis Fan Prole item appears when you enable the Chassis Q-Fan
Control feature.
Chassis Fan Prole [Optimal]
Allows you to set the appropriate performance level of the chassis Q-Fan. When
set to [Optimal], the chassis fan automatically adjusts depending on the chassis
temperature. Set this item to [Silent Mode] to minimize fan speed for quiet chassis
fan operation, or [Performance Mode] to achieve maximum chassis fan speed.
Conguration options: [Optimal] [Silent Mode] [Performance Mode][Optimal] [Silent Mode] [Performance Mode]
OPT Q-Fan and Temperature
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Temperature 1 Reading :N/A
Temperature 1 Reading :N/A
Temperature 1 Reading :N/A
OPT_Fan 1 Reading :N/A
OPT_Fan1 Q-Fan Control [DUTY CYCLE]
Duty Cycle Mode [90%]
OPT_Fan 2 Reading :N/A
OPT_Fan2 Q-Fan Control [DUTY CYCLE]
Duty Cycle Mode [90%]
OPT_Fan 3 Reading :N/A
OPT_Fan3 Q-Fan Control [DUTY CYCLE]
Duty Cycle Mode [90%]
Power Fan Reading :N/A
Fan conguration
mode setting
BIOS SETUP UTILITY
Power
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
