Asus ESC4000 G4S User Manual

2-47
ASUS ESC4000 G4 Series
2.8.3 U.2 drives
1
2
Storage device bay 7 and 8
To install a U.2 drive:
1. Install the U.2 drive to storage device bay 7 or 8.
Refer to section 2.4.2 Installing the 2.5-inch SATA/SAS/NVME storage device for the
steps on installing a 2.5-inch drive to the storage device bay.
2. Remove the OCuLink cables from the internal SAS/HBA/Storage bracket.
OCuLink cable 2
OCuLink cable 1
For the ESC4000 G4, the U.2 drives may be installed in storage device bay 7 and 8 as shown
in the illustration below:
ESC4000 G4

Asus ESC4000 G4S Specifications

General

Chipset	Intel C621
Form Factor	4U Rackmount
GPU Support	Supports up to 4 double-width GPUs
Processor	Intel Xeon Scalable processors
Memory	Up to 3TB DDR4 ECC RDIMM/LRDIMM
Memory Slots	16 x DIMM slots
Storage	8 x 3.5" hot-swap storage bays
Networking	2 x 10GBase-T LAN ports
Power Supply	1+1 Redundant 1600W 80 PLUS Platinum Power Supply
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
