Asus ESC4000 G4S User Manual

4-4
Chapter 4: Motherboard Information
4.2 Jumpers
1. Clear RTC RAM (CLRTC1)
This jumper allows you to clear the CMOS memory system setup parameters by
erasing the CMOS Real Time Clock (RTC) RAM data. The onboard button cell battery
powers the RAM data in CMOS, which include system setup information such as
system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap on pins 2–3
for about 5–10 seconds, then move the cap back to pins 1–2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup to re-
enter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
If the steps above do not help, remove the onboard battery and move the jumper again to
clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery.

Asus ESC4000 G4S Specifications

General

Chipset	Intel C621
Form Factor	4U Rackmount
GPU Support	Supports up to 4 double-width GPUs
Processor	Intel Xeon Scalable processors
Memory	Up to 3TB DDR4 ECC RDIMM/LRDIMM
Memory Slots	16 x DIMM slots
Storage	8 x 3.5" hot-swap storage bays
Networking	2 x 10GBase-T LAN ports
Power Supply	1+1 Redundant 1600W 80 PLUS Platinum Power Supply
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
