Asus H110M-PLUS - Rear Panel Connectors

ASUS H110M-PLUS
1-5
1. PS/2 mouse port (green).ThisportisforaPS/2mouse.
2. Video Graphics Adapter (VGA) port.This15-pinportisfora
VGAmonitororotherVGA-compatibledevices.
3. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoa
LocalAreaNetwork(LAN)throughanetworkhub.
 LAN port LED indications
Rear panel connectors
2
4 53
6
89 7
1
12
11 10
4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother
audiosources.
5. Line Out port (lime).Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1
and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
6. Microphone port (pink).Thisportconnectstoamicrophone.
Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or
7.1-channelconguration.
Activity/Link LED
Speed LED
Status Description
Status
Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbpsconnection
Orange(Blinking
thensteady)
Readytowakeup
fromS5mode
_ _
LAN port
Speed
LED
Activity Link
LED
