1-4
Chapter 1: Product introduction
• Werecommendthatyouconnectahigh-denitionfrontpanelaudio
moduletothisconnectortoavailofthemotherboard’shigh-denitionaudio
capability.
• Ifyouwanttoconnectahigh-denitionfrontpanelaudiomoduleto
thisconnector,settheFrontPanelTypeitemintheBIOSsetupto[HD
Audio].IfyouwanttoconnectanAC’97frontpanelaudiomoduletothis
connector,settheitemto[AC97].Bydefault,thisconnectorissetto[HD
Audio].
PCI Express 3.0/2.0 x1 slots
ThismotherboardsupportsPCIExpressx1networkcards,SCSIcards,andother
cardsthatcomplywiththePCIExpressspecications.
PCI Express 3.0/2.0 x16 slot
ThismotherboardhasonePCIExpress3.0/2.0x16slotthatsupportsPCIExpress
3.0/2.0x16graphiccardscomplyingwiththePCIExpressspecications.
WhenusingPCIcardsonsharedslots,ensurethatthedriverssupport“ShareIRQ”orthat
thecardsdonotneedIRQassignments.Otherwise,conictswillarisebetweenthetwoPCI
groups,makingthesystemunstableandthecardinoperable.
IRQ assignments for this motherboard
A B C D
PCIEx16_1 shared – – –
PCIEx1_1 shared – – –
PCIEx1_2 – shared – –
Realtek8111H – – – shared
HighDenitionAudio shared – – –
SATAController shared – – –
XHCIController shared – – –
AsmediaASM1142 shared – – –
