Asus H170M-PLUS - Onboard LED

ASUS H170M-PLUS
1-23
H170M-PLUS
H170M-PLUS Standby power LED
SB_PWR
ON
Standby Power Powered Off
OFF
12. TPM connector (14-1 pin TPM)
ThisconnectorsupportsaTrustedPlatformModule(TPM)system,whichcansecurely
storekeys,digitalcerticates,passwords,anddata.ATPMsystemalsohelpsenhance
networksecurity,protectsdigitalidentities,andensuresplatformintegrity.
The TPM module is purchased separately.
1.8 Onboard LED
1. Standby Power LED (SB_PWR)
ThemotherboardcomeswithastandbypowerLEDthatlightsuptoindicatethatthe
systemisON,insleepmode,orinsoft-offmode.Thisisareminderthatyoushould
shutdownthesystemandunplugthepowercablebeforeremovingorplugginginany
motherboardcomponent.TheillustrationbelowshowsthelocationoftheonboardLED.
H170M-PLUS
H170M-PLUS TPM connector
TPM
PIN 1
+3V
+3V
C_PCICLK_TPM
GND
S_PCIRST#_TBD
+3VSB
F_LAD0
F_LAD1
F_LAD2
F_LAD3
F_FRAME#
F_SERIRQ
TPM_PD#
