2.5.3 DRAM Odd Ratio Mode [Enabled]
AllowsyoutoenableordisabletheOddRatioMode,whichprovidesbettergranularity.
Congurationoptions:[Disabled][Enabled]
2.5.4 DRAM Frequency [Auto]
Thisitemallowsyoutosetthememoryoperatingfrequency.Thecongurableoptionsvary
withtheBCLK(baseclock)frequencysetting.Selecttheautomodetoapplytheoptimized
setting.Congurationoptions:[DDR4‑800MHz][DDR4‑933MHz][DDR4‑1066MHz][DDR4‑
1200MHz][DDR4‑1333MHz][DDR4‑1400MHz][DDR4‑1500MHz][DDR4‑1600MHz]
[DDR4‑1700MHz][DDR4‑1733MHz][DDR4‑1800MHz][DDR4‑1866MHz][DDR4‑1900MHz]
[DDR4‑2000MHz][DDR4‑2100MHz][DDR4‑2133MHz][DDR4‑2200MHz][DDR4‑2266MHz]
[DDR4‑2300MHz][DDR4‑2400MHz][DDR4‑2500MHz][DDR4‑2533MHz][DDR4‑2600MHz]
[DDR4‑2666MHz][DDR4‑2700MHz][DDR4‑2800MHz][DDR4‑2900MHz][DDR4‑2933MHz]
[DDR4‑3000MHz][DDR4‑3066MHz][DDR4‑3100MHz][DDR4‑3200MHz][DDR4‑3333MHz]
[DDR4‑3466MHz][DDR4‑3600MHz][DDR4‑3733MHz][DDR4‑3866MHz][DDR4‑4000MHz]
[DDR4‑4133MHz][DDR4‑4266MHz]
Selectingaveryhighmemoryfrequencymaycausethesystemtobecomeunstable!Ifthis
happens,reverttothedefaultsetting.
2.5.5 GPU Boost [Keep Current Settings]
EnablethisitemtoacceleratetheintegratedGPUforextremegraphicsperformance.
Congurationoptions:[KeepCurrentSettings][Enabled]
2.5.6 EPU Power Saving Mode [Disabled]
ASUSEPU(EnergyProcessingUnit)setstheCPUinitsminimumpowerconsumption
settings.EnablethisitemtosetlowerCPUVCCINandVcorevoltagesandachievethebest
energysavingcondition.Congurationoptions:[Disabled][Enabled]
2.5.7 CPU SVID Support [Auto]
DisablingSVIDSupportstopstheprocessorfromcommmunicatingwiththeexternalvoltage
regulator.Congurationoptions:[Auto][Disabled][Enabled]
2.5.8 DRAM Timing Control
ThesubitemsinthismenuallowyoutosettheDRAMtimingcontrolfeatures.Usethe
<+>and<‑>keystoadjustthevalue.Torestorethedefaultsetting,type[auto]usingthe
keyboardandpressthe<Enter>key.
Changingthevaluesinthismenumaycausethesystemtobecomeunstable!Ifthis
happens,reverttothedefaultsettings.
2-22 Chapter 2: Getting started
