Asus H170M-PLUS - Platform Misc Configuration

Package C State Limit [Auto]
ThisitemallowsyoutosettheaC‑statesupportfortheCPUpackage.
Congurationoptions:[Auto][C0/C1][C2][C3][C6][C7][C7s]
CFG Lock [Enabled]
ThisitemallowsyoutocongureMSR0xE2[15],CFGlockbit.Congurationoptions:
[Disabled][Enabled]
2.6.2 Platform Misc Configuration
Theitemsinthismenuallowyoutoconguretheplatform‑relatedfeatures.
PCI-E Native Power Management [Disabled]
ThisitemallowsyoutoenhancethepowersavingfeatureofPCIExpressandperformASPM
operationsintheoperatingsystem.Congurationoptions:[Disabled][Enabled]
ThefollowingitemappearsonlywhenyousetthePCIExpressNativePowerManagement
to [Enabled].
Native ASPM [Disabled]
[Enabled] Windows
®
VistaOScontrolstheASPM(activestatepower
management)supportfordevices.
[Disabled] BIOScontrolstheASPMsupportforthedevice.
PCH - PCI Express options
DMI Link ASPM Control [Disabled]
ThisitemallowsyoutocontroltheActiveStatePowerManagementonbothNB
(NorthBridge)sideandSB(SouthBridge)sideoftheDMILink.Congurationoptions:
[Disabled][Enabled]
ASPM Support [Disabled]
ThisitemallowsyoutoselecttheASPMstateforenergy‑savingconditions.Conguration
options:[Disabled][L0s][L1][L0sL1][Auto]
SA - PCI Express options
DMI Link ASPM Control [Disabled]
ThisitemallowsyoutocontroltheActiveStatePowerManagementonbothCPUandPCH
(platformcontrollerhub)BothDMIlinkASPMcontrolitemsoftheCPUandPCHsidesmust
beenabledfortheASPMtotakeeffect.Congurationoptions:[Disabled][L1]
PEG ASPM [Disabled]
ThisitemallowsyoutoselecttheASPMstateforenergy‑savingconditions,orusetheASUS
optimizedenergysavingprole.Congurationoptions:[Disabled][Auto][ASPML0s][ASPM
L1][ASPML0sL1]
ASUS H170M-PLUS 2‑31
