2.6.4 PCH-IO Configuration
ThisitemallowsyoutocongurethePCIExpresscongurationsettings.
PCI Express Configuration
AllowsyoutocongurePCIExpresssettings.
PCIe Speed [Auto]
AllowsyoutocongurethePCIespeed.Congurationoptions:[Auto][Gen1][Gen2]
[Gen3]
2.6.5 SATA Configuration
WhileenteringSetup,theBIOSautomaticallydetectsthepresenceofSATAdevices.The
SATAPortitemsshowNot PresentifnoSATAdeviceisinstalledtothecorrespondingSATA
port.
SATA Controller(s) [Enabled]
EnablesordisablesonboardtheSATAdevice.Congurationoptions:[Disabled][Enabled]
SATA Mode Selection [AHCI]
AllowsyoutosettheSATAconguration.
[AHCI] Setto[AHCI]whenyouwanttheSATAharddiskdrivestousetheAHCI
(AdvancedHostControllerInterface).TheAHCIallowstheonboardstorage
drivertoenableadvancedSerialATAfeaturesthatincreasesstorage
performanceonrandomworkloadsbyallowingthedrivetointernally
optimizetheorderofcommands.
[RAID] Setto[RAIDMode]whenyouwanttocreateaRAIDcongurationfromthe
SATAharddiskdrives.
ThefollowingitemsappearonlywhenyousettheSATAModeSelectionto[RAID].
CR#1/2/3 RST Pcie Storage Remapping [Disabled]
ThisitemallowsyoutoenableordisabletheRSTPcieStorageRemappingfeature.
Congurationoptions:[Auto][Disabled][Enabled]
Alternate ID [Disabled]
ThisitemallowsyoutoenableordisablethereportforthealternatedeviceID.
Congurationoptions:[Auto][Disabled][Enabled]
SMART Self Test
ThisitemallowsyoutoenableordisabletheSMARTSelfTestonallHDDsduringPOST.
SATA6G_1/2/3/4/5/6 (Gray) [Enabled]
Allowsyoutoenable/disabletheSATA6G_1/2/3/4/5/6port.Congurationoptions:[Disabled]
[Enabled]
Hot Plug [Disabled]
Theseitemsallowyoutoenable/disableSATAHotPlugSupport.Congurationoptions:
[Disabled][Enabled]
