BCLK Frequency [Auto]
ThisitemappearsonlywhenyousetAi Overclock Tunerto[Manual]andallowsyoutoset
theBCLK(baseclock)frequencytoenhancethesystemperformance.Usethe<+>/<‑>to
adjustthevalue.Thevaluesrangefrom40.0MHzto500.0MHz.
WerecommendyoutosetthevaluebasedontheCPUspecication,ashighBCLK
frequenciesmaydamagetheCPUpermanently.
BCLK Spread Spectrum [Auto]
ThisitemallowsyoutoenhancetheBCLKoverclockingcapabilityorreducetheEMI
(electromagneticdisturbance)generatedbytheBCLK.Setthisitemto[Enabled]forEMI
reduction,orsetthisitemto[Disabled]toenhanceBCLKoverclocking.Congurationoptions:
[Auto][Disabled][Enabled]
2.5.2 CPU Core Ratio [Auto]
ThisitemallowsyoutosettheCPUcoreratiolimitpercoreorsynchronizeautomaticallyto
allcores.Congurationoptions:[Auto][SyncAllCores][PerCore]
WhentheCPU Core Ratioissetto[Sync All Cores]or[Per Core],thefollowingitems
appear.
1-Core Ratio Limit [Auto]
Select[Auto]toapplytheCPUdefaultTurboRatiosettingormanuallyassigna1‑CoreLimit
valuethatmustbehigherthanorequaltothe2‑CoreRatioLimit.
2-Core Ratio Limit [Auto]
Select[Auto]toapplytheCPUdefaultTurboRatiosettingormanuallyassigna2‑CoreLimit
valuethatmustbehigherthanorequaltothe3‑CoreRatioLimit.
Ifyouassignavaluefor2‑CoreRatioLimit,donotsetthe1‑CoreRatioLimitto [Auto].
3-Core Ratio Limit [Auto]
Select[Auto]toapplytheCPUdefaultTurboRatiosettingormanuallyassigna3‑CoreLimit
valuethatmustbehigherthanorequaltothe4‑CoreRatioLimit.
Ifyouassignavaluefor3‑CoreRatioLimit,donotsetthe1‑CoreRatioLimitand2‑Core
RatioLimitto[Auto].
4-Core Ratio Limit [Auto]
Select [Auto]toapplytheCPUdefaultTurboRatiosettingormanuallyassigna4‑CoreLimit
valuethatmustbehigherthanorequaltothe3‑CoreRatioLimit.
Ifyouassignavaluefor4‑CoreRatioLimit,donotsetthe1‑CoreRatioLimit,2‑CoreRatio
Limit,and3‑CoreRatioto[Auto].
