2.7.4 Q-Fan Configuration
Ofan Tuning
Clickthisitemtoautomaticallydetectthelowestspeedandconguretheminimumdutycycle
foreachfan.
CPU Q-Fan Control [PWM Mode]
[Disabled] DisablestheQ‑Fancontrol.
[PWMMode] EnablestheCPUQ‑FancontrolfeatureinPWMmodefor4‑pinCPUfan.
CPU Fan Speed Lower Limit [200 RPM]
ThisitemappearsonlywhenyouenabletheCPUQ‑FanControlfeatureandallowsyou
todisableorsettheCPUfanwarningspeed.Congurationoptions:[Ignore][100RPM]
[200RPM][300RPM][400RPM][500RPM]
CPU Fan Profile [Standard]
ThisitemappearsonlywhenyouenabletheCPUQ‑FanControlfeatureandallowsyouto
settheappropriateperformanceleveloftheCPUfan.
[Standard] Setsto[Standard]tomaketheCPUfanautomaticallyadjustdependingon
theCPUtemperature.
[Silent] Setsto[Silent]tominimizethefanspeedforquietCPUfanoperation.
[Turbo] Setsto[Turbo]toachievemaximumCPUfanspeed.
[Manual] Setsto[Manual]toassigndetailedfanspeedcontrolparameters.
ThefollowingfouritemsappearonlywhenyousetCPU Fan Profileto[Manual].
CPU Upper Temperature [70]
Usethe<+>and<‑>keystoadjusttheupperlimitoftheCPUtemperature.Thevalues
rangefrom25ºCto75ºC.
CPU Fan Max. Duty Cycle(%) [100]
Usethe<+>and<‑>keystoadjustthemaximumCPUfandutycycle.Thevalues
rangefrom20%to100%.WhentheCPUtemperaturereachestheupperlimit,the
CPUfanwilloperateatthemaximumdutycycle.
CPU Middle Temperature [25]
Usethe<+>or<‑>keystosetthevalueforCPUMiddleTemperature.Therangeof
thevaluesdependsontheCPUinstalled.
CPU Fan Middle Duty Cycle(%) [20]
Usethe<+>or<‑>keystoadjusttheCPUfanmiddledutycycle.Thevaluesrange
from20%to100%.WhentheCPUtemperaturereachestheupperlimit,theCPUfan
operatesatthemaximumdutycycle.
CPU Lower Temperature [20]
Usethe<+>or<‑>keystoadjusttheCPUfan’slowertemperature.Thevaluesrange
from20°Cto75°C.
