H87I-PLUS specications summary
CPU LGA1150 socket for Intel
®
4th Generation Core
TM
i7/ i5 / i3, Pentium
®
,
Celeron
®
Processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H87 Express Chipset
Memory 2 x U-DIMM, max. 16GB DDR3 1600/1333/1066MHz, non-ECC, unbuffered
memory modules
Dual-channel memory architecture
* The maximum 16GB memory capacity can be supported with 8GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitation, DDR3 1600MHz and higher memory modules on
XMP mode will run at the maximum transfer rate of DDR3 1600MHz.
Graphics Multi-VGA output support: HDMI/DVI/D-Sub port
- Supports HDMI with max. resolution 4096 x 2304@24Hz / 2560 x
1600@60Hz
- Supports DVI with max. resolution 1920 x1200@60Hz
- Supports D-Sub with max. resolution 1920x1200@60Hz
* Max. UMA Memory: 1024MB
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot
Storage
Intel
®
H87 Express Chipset:
- 6 x Serial ATA 6Gb/s connectors (yellow)
- Support RAID 0, 1, 5, 10 mode
LAN
Intel
®
I217 Gigabit LAN Controller
Audio Realtek
®
ALC887 8-Channel High Denition Audio CODEC
* Use a chassis with HD audio module in the front panel to support a 8-
channel audio output
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H87I-PLUS motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
