1.7 Connectors
1.7.1 Rear panel connectors
1. PS/2 Mouse port.ThisportconnectstoaPS/2mouse.
2. Video Graphics Adapter (VGA) port. This15-pinportisforaVGAmonitororother
VGA-compatibledevices.
3. HDMI port.ThisportisforaHigh-DenitionMultimediaInterface(HDMI)connector,
andisHDCPcompliantallowingplaybackofHDDVD,Blu-ray,andotherprotected
content.
4. LAN (RJ-45) port.TheseportsallowGigabitconnectiontoaLocalAreaNetwork
(LAN)throughanetworkhub.
LAN port LED indications
LAN port
SPEED
LED
ACT/LINK
LED
2
5 64
79
9 8
1
11
3
10
5. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother
audio sources.
6. Line Out port (lime). Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1,
and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
7. Microphone port (pink). This port connects to a microphone.
Refertotheaudiocongurationtableonthenextpageforthefunctionoftheaudioportsin
2.1,4.1,5.1,or7.1-channelconguration.
Activity/Link LED Speed LED
Status Description Status Description
Off No link OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange
(Blinking)
Dataactivity GREEN 1Gbps connection
Orange
(Blinkingthen
steady)
Readyto
wake up from
S5mode
