H97-PLUS specifications summary
(continued on the next page)
CPU LGA1150 socket for the 4th Generation, New 4th Generation and 5th
Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3, Pentium
®
, and
Celeron
®
processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H97 Express Chipset
Memory 4 x DIMM, max. 32GB, DDR3 1600 / 1333 MHz, non-ECC, un-buffered
memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Refer to www.asus.com for the Memory QVL (Qualified Vendors List).
** Due to Intel
®
chipset limitation, DDR3 1600 MHz and higher memory modules
on XMP mode will run at the maximum transfer rate of DDR3 1600 MHz.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 2.0 x16 slot* (max at x4 mode, compatible with PCIe x1
and x4 devices)
2 x PCI Express 2.0 x1 slots**
2 x PCI slots
* The PCIe x16_2 slot runs at x2 mode as default. See the BIOS section for the
detailed configuration.
**
The PCIe x1_1 and PCIe x1_2 slots share bandwidth with the PCIe x16_2 slot.
Graphics
Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI, DVI-D, RGB port
Supports HDMI with max. resolution of 4096 x 2160 @24Hz / 2560 x 1600
@60Hz
Supports DVI-D with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru™ 3D, Intel
®
Quick Sync Video, Intel
®
Clear Video HD
Technology, and Intel
®
Insider™
Supports up to three displays simultaneously
Maximum shared memory of 512MB
Package contents
Check your motherboard package for the following items.
Motherboard ASUS H97-PLUS motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
